TIRE PRESSURE WARNING SYSTEM FAIL-SAFE CHART


  1. FAIL-SAFE FUNCTION


    1. When a malfunction occurs in the tire pressure warning system, the tire pressure warning light illuminates after blinking for 1 minute to inform the driver of the system failure.

    2. As a result of this, tire pressure monitoring is disabled and a DTC is stored in the tire pressure warning ECU and receiver.

    3. w/ Tire Inflation Display Function:

      When there is a system malfunction, the output display according to the tire position turns off.

      Tech Tips

      Spare tire is only displayed on vehicles with full size spare tire.

      B0070O2C02
      *A for 4.2 Inch Display *B for 7 Inch Display
