SPOT LIGHT COMPONENTS
ILLUSTRATION
*A |
w/ Audio |
*B |
for Radio Receiver Type |
*C |
for Radio and Display Type |
*D |
w/o Audio |
*1 |
AIR CONDITIONING CONTROL ASSEMBLY |
*2 |
CENTER NO. 1 INSTRUMENT CLUSTER FINISH PANEL |
*3 |
INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY |
*4 |
NO. 2 INSTRUMENT PANEL GARNISH SUB-ASSEMBLY |
*5 |
NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY |
*6 |
NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY |
*7 |
RADIO AND DISPLAY RECEIVER ASSEMBLY |
*8 |
RADIO RECEIVER ASSEMBLY |
*9 |
STEREO OPENING COVER |
- |
- |
 |
N*m (kgf*cm, ft.*lbf): Specified torque |
- |
- |
