BODY PANEL ANTI-CHIPPING PAINT APPLICATION AREAS
CAUTION:
Work must be performed while wearing the appropriate protective gear and in a well-ventilated area.
-
To protect the body from damage due to gravel, apply the anti-chipping paint to the rocker panels, roof panel, front body pillar, doors, wheel arches and hood.
Tech Tips
-
Apply anti-chipping paint to the indicated areas first, before applying the top coat.
-
If anti-chipping paint is unnecessarily applied to an area, apply degreasing agent to a clean cloth and clean the paint off immediately.
-
| *1 | Soft-Chipping Primer |
| *2 | Protection Tape |
| *3 | Anti-chipping Paint (Intermediate Coat) |
| *1 | Anti-chipping Paint (Intermediate Coat) |
| *2 | Protection Tape |
